Get the Guaranteed Best A307 Elevator Bolts Low carbon steel Rates at Sunflex Metal Industries

You are here : Home » Products » Fasteners Types » A307 Elevator Bolts Low carbon steel

Fasteners Specification / BS Fasteners / ISO Fasteners / DIN Specification / Flat Washer Standards | Check Price

A307 Elevator Bolts Low carbon steel, Zinc

A307 Elevator Bolts A307 Elevator Bolts Low carbon steel, Zinc

Elevator Bolts are designed with a wide, countersunk flat head, commonly used in conveyor systems.

A307 Elevator Bolts Low carbon steel, Zinc

Length of an elevator bolt is measured from the top of the head to the extreme end of the bolt.
ANSI/ASME B18.5A307 Elevator Bolts
Nominal Size	Body Diameter		Head Diameter			Head Height		Square Width		Square Depth
Nominal Size	Max.	Min.	Max. Edge Sharp	Min. Edge Sharp	Min. Edge Flat	Max.	Min.	Max.	Min.	Max.	Min.`
1/4	0.260	0.237	1.008	0.969	0.938	0.098	0.078	0.280	0.245	0.219	0.188
5/16	0.324	0.298	1.227	1.188	1.157	0.114	0.094	0.342	0.307	0.250	0.219
3/8	0.388	0.360	1.352	1.312	1.272	0.145	0.125	0.405	0.368	0.250	0.219
Tolerance on Length			Nominal Bolt Size			Nominal Bolt Length
			Nominal Bolt Size			Up to 1 in., incl.		Over 1 in. to 2-1/2 in., incl.		Over 2-1/2 in. to 4 in., incl.
			1/4 thru 3/8			+0.02, -0.03		+0.02, -0.04		+0.04, -0.06

Types of Bolts
Hex Head Bolt	Socket Cap Screw	Carriage Bolt	Anchor Bolt	Eye Bolt
Flange Bolt	Elevator Bolt	Lag Bolt	Draw Bolt	Plow Bolt
Stove Bolt	Tap Bolt	Machine Bolt	Hanger Bolt	U Bolt
Grub Screw	Set Screw	Shoulder Bolt	Step Bolt	J Bolt

A307 Elevator Bolts Low carbon steel Application Industries

Sunflex Metal Industries are engaged in manufacturing of robust quality of A307 Elevator Bolts Low carbon steel. These A307 Elevator Bolts Low carbon steel are widely used in the following industries:

Mining Industries
Transport Industries- Rail and Road
Construction Industries / Building Systems
Manufacturing Industries
Agriculture Industries
Energy Industries
Water Industries
Automotive Industries
Ship Building Industries
Nuclear Power Plant
Paper & Pulp Industries
Sugar Industries
Engineering Cement Industries
Petro-Chemical Industries
Food Industries
Oil & Gas Industries
Chemical & Pharmaceutical Industries

Share This Page

Get the Guaranteed Best A307 Elevator Bolts Low carbon steel Rates at
Sunflex Metal Industries

Fasteners

Free Sample with best price in asia of A307 Elevator Bolts Low carbon steel. / A307 Elevator Bolts Low carbon steel Best Price Guarantee.

Check Our Price Before you buy A307 Elevator Bolts Low carbon steel / Sunflex Metal Industries manufacturer and Supplier working since 1982 and applying for a fast growing company of fasteners, A307 Elevator Bolts Low carbon steel.

A307 Elevator Bolts Low carbon steel, Zinc
